Matrix Orbital GTT70A - Manual (Page 18)

Command Summary 14
4.5 Enable Manual
Update Dec
Hex
ASCII 254 90
FE 5A
þ Z
Enable
Enable
Enable 2.0
Stop all drawing commands from automatically updating the screen, send them to the display buffer, and allow a
manual update to execute all updates at one time. Useful for displaying a complicated image as a single visual
update. Default is disabled.
Enable Byte Desired manual update setting, as per eEnable values.
Table 14: eEnable values
Value Description
0 Disable
1 Enable
4.6 Manual Update Dec
Hex
ASCII 254 91
FE 5B
þ [
2.0
Immediately push the contents of the display buffer to the screen. This has no effect if manual update is disabled.
4.7 Flush Region Dec
Hex
ASCII 254 92
FE 5C
þ \
X Y Width Height
X Y Width Height
X Y Width Height 2.0
Manually flush all graphic data in a specified region to the screen.
X Signed Short Leftmost coordinate of the flush window.
Y Signed Short Topmost coordinate of the flush window.
Width Signed Short Width of the flush window.
Height Signed Short Height of the flush window.
4.8 Set Drawing
Colour Dec
Hex
ASCII 254 99
FE 63
þ c
R G B
R G B
R G B 2.0
Set the colour to be used for all future drawing commands. The default colour is white.
R Byte Intensity of red, 0 to 255, limited to display metrics.
G Byte Intensity of green, 0 to 255, limited to display metrics.
B Byte Intensity of blue, 0 to 255, limited to display metrics.
