Command Summary 16
4.14 Draw Filled
Rectangle Dec
Hex
ASCII 254 120
FE 78
þ x
X Y Width Height
X Y Width Height
X Y Width Height 2.0
Draw a filled rectangle using the current drawing colour.
X Signed Short Leftmost coordinate of the rectangle.
Y Signed Short Topmost coordinate of the rectangle.
Width Short Width of the rectangle.
Height Short Height of the rectangle.
4.15 Draw Circle Dec
Hex
ASCII 254 123
FE 7B
þ {
X Y Radius
X Y Radius
X Y Radius 2.0
Draw a circular frame one pixel wide using the current drawing colour.
X Signed Short Horizontal coordinate of circle centre.
Y Signed Short Vertical coordinate of circle centre.
Radius Short Radius of the circle. Diameter will be twice radius, plus one centre pixel.
4.16 Draw Filled
Circle Dec
Hex
ASCII 254 124
FE 7C
þ |
X Y Radius
X Y Radius
X Y Radius 2.0
Draw a filled circle using the current drawing colour.
X Signed Short Horizontal coordinate of circle centre.
Y Signed Short Vertical coordinate of circle centre.
Radius Short Radius of the circle. Diameter will be twice radius, plus one centre pixel.
4.17 Draw an
Ellipse Dec
Hex
ASCII 254 125
FE 7D
þ }
X Y XRadius YRadius
X Y XRadius YRadius
X Y XRadius YRadius 2.0
Draw an elliptical frame one pixel wide using the current drawing colour.
X Signed Short Horizontal coordinate of ellipse centre.
Y Signed Short Vertical coordinate of ellipse centre.
XRadius Short Horizontal Radius of the ellipse.
YRadius Short Vertical Radius of the ellipse.
4.18 Draw a Filled
Ellipse Dec
Hex
ASCII 254 126
FE 7E
þ ~
X Y XRadius YRadius
X Y XRadius YRadius
X Y XRadius YRadius 2.0
Draw a filled ellipse using the current drawing colour.
X Signed Short Horizontal coordinate of ellipse centre.
Y Signed Short Vertical coordinate of ellipse centre.
XRadius Short Horizontal Radius of the ellipse.
YRadius Short Vertical Radius of the ellipse.
