31 Command Summary
10.3 Define A 9-
Slice Bargraph Dec
Hex
ASCII 254 104
FE 68
þ h
Index Min Max X Y Width Height BFG BBG D
Index Min Max X Y Width Height BFG BBG D
Index Min Max X Y Width Height BFG BBG D 2.0
Define a region of the screen to be used to display a new 9-slice bargraph identified by the specified index. New
indices will overwrite old, invalid directions will default to 0, and inverted min and max values will be corrected.
Index Byte Index used to identify the desired bargraph. Specific to bargraphs.
Min Signed Short Minimum bargraph value.
Max Signed Short Maximum bargraph value.
X Signed Short Leftmost coordinate of the bargraph.
Y Signed Short Topmost coordinate of the bargraph.
Width Signed Short Width of the bargraph.
Height Signed Short Height of the bargraph.
BFG Byte 9-Slice buffer index of the foreground image.
BBG Byte 9-Slice buffer index of the background image.
D Byte Direction that the bargraph will take, as per eBargraphOrientation values.
10.4 Update A
Bargraph Value Dec
Hex
ASCII 254 105
FE 69
þ i
Index Value
Index Value
Index Value 2.0
Update the value of the specified bargraph. Value will be bounded to the bargraph minimum and maximum.
Index Byte Index used to identify the desired bargraph. Specific to bargraphs.
Value Signed Short Current value of the bargraph.
Return Message 252 105 Length Result
Result Byte Outcome of Update A Bargraph Value command, as pereErrorCode values.
10.5 Update
Multiple
Bargraph Values Dec
Hex
ASCII 254 106
FE 6A
þ j
Index Length Values
Index Length Values
Index Length Values 2.0
Update the values of the specified bargraphs. Values will be bounded to the bargraph minimum and maximum.
Index Byte Index used to identify the first desired bargraph. Specific to bargraphs.
Length Byte Length of the data to be transferred, in bytes.
Values Signed Short(s) Current values, one for each bargraph index to be updated.
Return Message 252 106 Length Result
Result Byte Outcome of Set Multiple Bargraph Values command, as pereErrorCode
values.
10.6 Clear All
Bargraphs Dec
Hex
ASCII 254 107
FE 6B
þ k
2.0
Clear all bargraphs entries, erasing all attributes and setting all to an unused state.
