Ashcroft GC52 - Rangeable wet/wet Differential Pressure Transmitter - Manual (Page 7)

7
7. Rangeability /
Adjustment
8. Display
9. Units
10. Setting Adjustments
11. Enclosure
12. Pressure Connection
13. Electrical
Termination
14. Memory Protection
15. EMC Directive
16. Operating
Temperature
17. Storage
Temperature
18. Vibration
19. Shock
20. Insulation
Resistance
21. Weight
Zero: –10 to +110% FS
Span: –10 to + 110% FS
Character height: 10mm, with LCD display with LED
backlight
Pressure / linear display: (4) LCD digits max.
Display update: 500 ms
Pressure Units: inH
2
O (2), (1) arbitrary
Internal key switches (Mode, T, S)
Scaling function: Linear output, linear and momentary
flow rate display/output.
Filter function: User adjustable output damping select
from 0, 2, 4, 8 and 16 (None, 2, 4, 8, and 16 (s)).
Loop check function: User adjustable output for loop/
system check and troubleshooting, 4-20mA.
Material: Aluminum die cast
Environmental Rating: IP65 / NEMA 4X
1 ⁄
4
NPT female pressure ports w/equalizing valve
Cable Gland (Optional): Cable diameter 0.35 to 0.47˝
(9-12mm)
1 ⁄
2
NPT Female Conduit Adapter (Optional)
Terminal Block: 14-22 AWG (stranded or solid wire)
Permanently stored by EEPROM (nonvolatile memory)
CE Compliance: EN61326/1997, A1/1998, A2/2001
–10 to 60°C (14 to 140°F)
–20 to 70°C (–4 to 158°F)
5g’s, 150Hz
10g’s, 16ms
50Vdc, 100M
Ω or more
Approx. 670g (1.5lbs)
