Ashcroft GC52 - Rangeable wet/wet Differential Pressure Transmitter User Manual
Page 25
25
Ⅵ Square root display and analog
Momentary flow rate display (arbitrary unit)
Differential pressure: 12IW Integrated volume display (arbitrary unit)
• Momentary flow rate 0.868 Integrated volume: 570616
• Analog output: 17.9 mA
0.868
570616
Differential
Momentary Flow
Pressure
Rate Unit
Analog Output
(IW)
(mA)
Span Point
16
1.000
20
|
|
|
12
0.868
17.9
|
|
|
Zero Point
0
0
4
Display alternation
whenever the
(M) key is pushed
(Manual)
