Setting of integrated volume

When a momentary flow rate unit is set as an arbitrary unit, the
integrated volume is also an arbitrary unit and the factor of the
two following points must be set:

• Setting of

time factor (second, minute, hour)

• Setting of

flow factor weight (1, 10, 100, 1000)

In the differential flow meter whose differential pressure generated
at maximum momentary flow rate of 1.000L/s is 16

I

W (80%F.S.)

and which uses a differential pressure range of 0 to 2.0

I

W, the

setting of momentary flow rate of arbitrary unit and the setting of
integrated volume of the arbitrary unit (in order to display 1 per
count) are as follows: In this case, the low-cut is set as 10%F.S.
and the display switching method is set as manual.

Select the “Square root display mode”

==>

Setting item

Set the differential pressure at max. momen-

tary flow rate as 16IW (80%F.S.)

==>

Setting item

Select “3-digit” as decimal point position

of momentary flow rate

==>

Setting item

Set the max. momentary flow rate as “1.000.”

==>

Setting item

Set the low-cut as “10.0%F.S.” of max.

display span*

==>

Setting item

Set the output zero point as “0.0%F.S.”

0 of max. display span*

==>

Setting item

Set the output span point as “100.0%F.S.”

1 of max. display span*

==>

Setting item

Select “SEC” (second) as time factor of

integrated volume

==>

Setting item

Select “1” as weight of flow factor of

integrated volume

==>

Setting item

k

21

Select “bt” (manual) as display

switching method

==>

Setting item

k

22

*Maximum display span: 0 to Maximum momentary flow rate
