14

9.

MODE CHANGES

Measurement Mode (Section 11 for further detail) will be entered upon
power-on. Setting Mode (Section 14 for further detail) is entered by
pressing and holding the MODE button for more than 3 seconds. If there
is no button operation for 10 minutes in the setting mode, it will shift back
to the Measurement Mode automatically.

To go from the Measurement Mode to the Zero Adjustment Mode (Sec-
tion 12 for further detail) press and hold the UP

T

button for more than

3 seconds.

10. POWER-ON MESSAGE

After the power is turned on, the power-on message is displayed for 6
seconds as shown below and then the display is shifted to the measure-
ment mode (section 11). In addition, the analog output during power-on
message is at the zero point (4mA).

8.8.8.8.8.8.

80.0

g[52

Power ON

Power on message

Measurement mode

Setting mode

Zero adjustment mode

(M) key for more than 3 seconds

() key for more than 3 seconds

(M) key for more than 3 seconds or if there
is no operation for 10 minutes

All lights
two seconds

Differential
pressure range
two seconds

Product

Finish
