Aalborg Vortex Insertion - Manual (Page 102)

97
COMMAND
NAME
DESCRIPTION
NO.
COMMAND SYNT
A
X
COMMAND
ARGUMENT 1
ARGUMENT 2
ARGUMENT 3
ARGUMENT 4
RESPONSE
Natural Gas AGA8 equation related parameters
Sets/Reads Natural Gas AGA8 equation related parameters. Mode: determines which parameter will be use in the equation.
27
NG
M Mode: 0- Gas Density @ TP 1 – Real Spec. Gravity @ TP
.
alue> 0 or 1
NGM:
alue> Example:NGM:0
No Argument (Ret. Current settings)
NGM:
alue>
Example: NGM:0
D Gas Density @ TP (Lb/Ft^3).
alue> (0.001-999.0)
NGD:
alue> Example: NGM:0.4994
No Argument (Ret. Current settings)
NGD:
alue>
Example: NGM:0.4994
G Real Spec. Gravity @ TP (no units).
alue> (0.001-999.0)
NGG:
alue> Example: NGG:0.309
No Argument (Ret. Current settings)
NGG:
alue>
Example: NGG:0.309
F Molecular Fracture for N2 and CO2. Sum (N2 & CO2) <
0.15.
alue> N2 Mol.
Fract. [0.0 – 0.15]
alue> CO2 M
Fract
[0.0 – 0.15]
NGF:
alue>,
alue>
Example: NGF:0.006,0.004
No Argument (Ret. Current settings)
NGF:
alue>,
alue>
Example: NGF:0.006,0.004
R Reference Temperature and Pressure (TP).
alue> Ref. T
emp.
(Deg. F) [-459–99999]
alue> Ref. Pressure
(PSIA) [0-99999]
NGR:
alue>,
alue>
Example: NGR:50.0,100.0
No Argument (Ret. Current settings)
NGR:
alue>,
alue>
Example: NGR:50.0,100.0
Other Gas
Sets/Reads Other Gas equation related parameters. Mode: determines which parameter will be use in the equation.
28
OG
M Specific Gravity Mode: 0- ratio of molecular weight G. 1 – Ratio of Densities Gr at flowing TP
.
alue> 0 or 1
NGM:
alue> Example:
NGM:0
No Argument (Ret. Current settings)
OGM:
alue>
Example:OGM:0
G Spec. Gravity Gr as Ratio of Densities at flowing TP (no units).
alue>
(0.001-999.0)
OGG:
alue> Example:
OGG:0.309
No Argument (ret. cur
. set.)
OGG:
alue> Example:
OGG:0.309
