Section 8. Buzzer Application
69
TONE SEQUENCE 2 PROPERTY
Property ID: 02 (Hex)
Property Type: Binary
Length: 20
Power Up/Reset Value: 0330 0220 0110 0000 0000 0000 0000 0000 0000 0000 (high tone for
480 ms, medium tone for 320 ms, low tone for 160 ms)
Get/Set/Save support: All
Description:
This property specifies an audible tone that may be played when the host chooses. The property
is implemented as ten sets of Tone Information Bytes (TIB) as follows:
Byte Usage
1 TIB0, designates tone
0 = Silent
1 = Low
2 = Medium
3 = High
Other values may not result in a tone
2 TIB1, duration of tone in units of 10 milliseconds (e.g. 3 = 30
milliseconds). Setting this byte to zero terminates the Tone Sequence
without processing further entries
Example Get Property Request:
Field MTYP APPL CMND RC PTYP PID
Byte 1 2 3 4 5 6
Value (Hex) 00 07 00 00 04 01
Example Get Property Response:
Field MTYP APPL CMND RC PTYP PID
Byte 1 2 3 4 5 6
Value (Hex) 40 07 00 00 04 01
PVAL
7-26
03 30 02 20 01 10 00 00 00 00 00 00 00 00 00 00 00 00 00 00
