Section 5. Smart Card Application
PROPERTIES
Reset Values marked with * are per ISO 7816-3(1997), or EMV 4.1. Changing these properties is not advisable unless the card you are
operating is non-standard.
General Properties used by the whole application. In order for these properties to influence a card session, they must be set before the card session
begins. Once set, these property values will persist for the current connector until a device reset, or until they are changed by further property
settings.
Name ID
(Hex)
Type Length Reset
Value
Get/Set/
Save
Description
CondRpt 00 Binary 15 N/A Get Operation Condition Report. This property only has meaning if the most
recent request was Power Up, Exchange APDU, or Exchange TPDU.
This property gives detailed information on the operation and is most
useful if the RC in the response was either Failure or Warning. See Error
/ Warning Condition Templates section for a detailed explanation of this
property.
CardType 01 Binary 1 0x00 Get/Set Card Type
See Card Types in this section for values
Volts 02 Binary 1 0x03* Get/Set Card Voltages allowed:
0x01 = 5 volts only
0x02 = 3 volts only
0x03 = 5 and 3 volts
UART-ID 03 Binary 11 N/A Get ID of Smart Card UART
Microprocessor Card Setup Properties, used to control the Power Up sequence. In order for these properties to influence a card session, they must
be set before the card session begins. Once set, these property values will persist for the current connector until a device reset, or until they are
changed by further property settings.
Name ID
(Hex)
Type Length Reset
Value
Get/Set Description
Initial ETU 15 Dword 2 372* Get/Set Initial value for ETU, in card clocks. Used to set bit time.
Initial CWT 16 Dword 2 449* Get/Set Maximum time, in 2 ms units, to wait between characters during the ATR.
In EMV Mode this property is set to 472 yielding 10080 etus.
Initial BWT 18 Dword 2 6* Get/Set Maximum time, in 2 ms units, to wait for first character of ATR after Reset
Default EGT 19 Dword 1 0* Get/Set Default EGT, used if card sends no EGT info in TC1.
Default BGT 1A Dword 1 22* Get/Set Default BGT, always used.
Power Up Error
Conditions
Template 1B Binary 4 (Hex)*
0F 00 00
00
Get/Set Used to define which conditions shall be considered errors when
powering up the card. The options in this bit-map are defined in the
description of the Power Up command.
31
