IntelliStripe 320 Command Reference
6
Response Message Data:
Byte Field Description
1 Property Type Property Type definition follows
2 Property ID Property ID identifies the property
3 Property Value Value of the property
The property type field is the same as defined in the request message data. Only valid property
types are returned. The property type None is never returned. If the property type is Dword, the
format of the property value is in the Intel LSB,MSB (Little Endian) layout. For example Dword
value 0x12345678 is formatted as 0x78 0x56 0x34 0x12. Four bytes are always returned.
Response Message Result Codes:
Success = 00 (Hex)
The command completed successfully.
Failure = 01 (Hex)
The command failed.
