IntelliStripe 320 Command Reference
8
SAVE PROPERTY COMMAND
Command ID: 02 (Hex)
Description:
This command is used to save the current property value as the power up / reset default value.
This command can be used to modify the property default values so that the properties do not
have to be initialized to other values after a power cycle or reset. Typically the set property
command is sent first to set the property to the desired power up / reset value. After which, the
save property command is sent to save the property in non-volatile memory so that it can then be
used as the new default value after a power cycle or reset. Not all properties support this
command. See the description of each property to see if this command is supported or not.
Request Message Data:
Byte Field Description
1 Property Type Property Type definition follows
2 Property ID Property ID identifies the property
3 Security Code 1 55 (hex)
4 Security Code 2 AA (hex)
Property Type definition:
The bits are identified by numbering the least significant bit 0 and the most significant bit 7.
Bits Value Definition
7-4
0 Reserved for future use.
0 Property type – None. The property type is unspecified.
1 Property type Dword – 32-bit integer.
2 Property type String – zero-terminated ASCII string.
3 Property type Boolean – 8-bit integer (1 – TRUE, 0 –
FALSE)
4 Property type Binary – binary data.
3-0
5–15 Property types reserved for future use.
Response Message Data: None
Response Message Result Codes:
Success = 00 (Hex)
The command completed successfully.
Failure = 01 (Hex)
The command failed.
