IntelliStripe 320 Command Reference
42
Byte Bit Meaning
0 6 TCK not present or incorrect. This condition only appears when the
ISO/EMV rules require a TCK and the card does not send it.
0 7 Card requests VPP. This condition occurs only if the card requests VPP.
This IFD does not support VPP.
1 0 Card started ATR early. This condition occurs when a card starts the ATR
too earlier than allowed by ISO or EMV rules.
1 1 Invalid TS. This condition indicates that the TS character had a value other
than 0x3B or 0x3F.
1 2 Unknown Interface Byte. This condition occurs when an interface byte not
defined by ISO 7816-3 or EMV is sent as part of the ATR.
1 3 Invalid Protocol Sequence. This condition occurs when the ATR specifies
protocols in a non-ascending order.
1 4 Specific Mode requesting Implicit Parameters. This condition happens
when the card sends TA2 with bit b5 (see ISO 7816-3(1997)) set.
1 5 TC2 present with T=0. This condition indicates that TC2 was sent in an
ATR that does not support T=0.
1 6 IFSC out of allowed range. This condition indicates that the card requested
an IFSC out of the range permitted by current rules. The current range is
specified by properties TA3 Minimum and TA3 Maximum.
1 7 Invalid EDC type requested. The card has requested an unsupported EDC
type. At this time the IFD only supports LRC.
2 0 PPS sequence failed. The IFD was unable to complete a successful PPS
sequence. In order to operate this card, it may be necessary to change
one or more of the following properties:
PPS Allowed
Protocol Selection Allowed
Speed Selection Allowed
Force PPS1 Transmission
See your card’s documentation for more details.
2 1 Parity Error in ATR.
2 2 EGT out of range. The EGT calculated from N in the ATR is larger than
254 ETUs.
2 3 TD2 not according to EMV rules. Indicates that TD2 does not conform to
EMV rules. The condition is only detected if the property EMV TD2 Rules
is set to TRUE.
2 4 T=15 received. This condition only indicates that the card sent a byte
specifying T=15.
2 5 TB2 received. This condition only indicates that the card sent a TB2 byte.
2 6 TC2 outside of allowed range. The card sent a TC2 byte out of the allowed
range. The allowed range is specified in properties TC2 Minimum and TC2
Maximum.
2 7 EMV TB3 error. This condition indicates that for a card requesting T=1
either TB3 was absent or the values specified for BWI or CWI were out of
range. See EMV, ICC, I-4.3.3.10
3 0-7 Reserved for Future Use
