IntelliStripe 320 Command Reference
94
Power Up
The Power Up command is issued as with Microprocessor cards and can get same Result Codes.
When the Result Code indicates an Error or Warning, the Primary Status of the CondRpt
Property will never be 0x03.
APDU Exchange Command
The APDU Exchange Command is used to control logical operations of the card between Power
Up and Power Down. The APDU is issued as with Microprocessor cards. The Result Codes are
the same as for Microprocessor cards. When the Result Code indicates an Error or Warning, the
Primary Status of the CondRpt Property will never be 0x03.
Two SW1/SW2 Status Codes may apply to any APDU:
SW1/SW2 Meaning
6E00
CLA Not Supported
6D00 INS Not Supported
Read Binary APDUl:
Command APDU:
CLA INS P1 P2 Le
00 B0 Adr1
Adr0 Len
CLA is always 00
INS is always B0
P1 is upper byte of address as follows:
80 reads Main Memory (Short File ID 0)
81 reads Security Memory (Short File ID 1) (SLE 4442 only)
84 reads Protection Memory (Short File ID 4)
P2 is lower byte of address within the requested Memory
Le is the number of bytes to read, 0-256, 0 indicates 256 bytes
Response APDU:
Data Field (from card)
SW1 SW2
When reading from the Protection Memory, the high order bit of the first data byte returned
represents the protection state of byte 0 in the Main Memory. The low order bit of the first data
byte returned represents the protection state of byte 7, etc.
