Section 4. Magnetic Stripe Application
21
Card Encode Type definition:
Value Encode Type Description
0 ISO/ABA ISO/ABA encode format
1 AAMVA AAMVA encode format
2 CADL CADL encode format. Note that some versions of this reader
can only read track 2 for this format. They can not read tracks 1
and 3. However, this format is obsolete. There should no
longer be any cards in circulation that use this format. California
is now using the AAMVA format.
3 Blank The card is blank
4 Other The card has a non-standard encode format. For example,
ISO/ABA track 1 format on track 2.
5 Undetermined The card encode type could not be determined because no
tracks could be decoded.
6 None No decode has occurred. This type occurs if no magnetic stripe
data has been acquired since the data has been cleared or
since the device was powered on.
7 JIS Type 2 JIS X 6302 Type 2 encode format
Response Message Result Codes:
Success = 00 (Hex)
The command completed successfully.
Bad Parameter = 06 (Hex)
The command failed due to a bad parameter in the request message data field
Example Request:
Field MTYP APPL CMND RC TRACK
Byte 1 2 3 4 5
Value (Hex) 00 01 82 00 02
Example Response:
Field MTYP APPL CMND RC TRACK DCD STAT ENCD TYP TK DATA
Byte 1 2 3 4 5 6 7 8 - 41
Value (Hex) 40 01 82 00 02 00 00 Track2
