Bluetooth MagneSafe V5 Swipe Reader
34
Example Set Post Track String property Response (Hex):
Result Code Data Len
Data
00
00
Example Get Post Track String property Request (Hex):
Cmd Num
Data Len
Prp ID
00
01
21
Example Get Post Track String property Response (Hex):
Result Code Data Len
Prp Value
00
03
31 32 33
TERMINATION STRING PROPERTY
Property ID:
0x22
Property Type:
String
Length:
0-7 bytes
Get Property:
Yes
Set Property:
Yes
Default Value:
0x0D (carriage return)
Description:
This string is sent after the all the data for a transaction. The string can be 0 –
7 bytes long. If the value is 0 no character is sent.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled for these changes to take effect.
FS PROPERTY
Property ID:
0x23
Property Type:
Byte
Length:
1 byte
Get Property:
Yes
Set Property:
Yes
Default Value:
0x7C (‘|’)
Description:
This character is sent as the field separator to delimit additional data
(MagnePrint info, reader info, DUKPT info, etc.). If the value is 0 no
character is sent. If the value is in the range 1 – 127 then the equivalent
ASCII character will be sent.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled for these changes to take effect.
