Bluetooth MagneSafe V5 Swipe Reader
14
The card data format for all programmable configuration options is as follows:
[P30]
[P32] [Tk1 SS] [Tk1 Masked Data] [ES] [P33]
[P32] [Tk2 SS] [Tk2 Masked Data] [ES] [P33]
[P32] [Tk3 SS] [Tk3 Masked Data] [ES] [P33]
[P31]
[P35] [Reader Encryption Status]
[P35] [Tk1 Encrypted Data (including TK1 SS and ES)]
[P35] [Tk2 Encrypted Data (including TK2 SS and ES)]
[P35] [Tk3 Encrypted Data (including TK3 SS and ES)]
[P35] [MagnePrint Status]
[P35] [Encrypted MagnePrint data]
[P35] [Device serial number]
[P35] [Encrypted Session ID]
[P35] [DUKPT serial number/counter]
[P35] [Encryption Counter] (optional, off by default)
[P35] [Clear Text CRC]
[P35] [Encrypted CRC]
[P35] [Format Code]
[P34]
The characters and fields are described in the list below. The Property ID (e.g., P13) is the
decimal value of the property ID in the command list (see Pre Card String).
Label
Property
ID
P-Value
Description
Default
0x1E
P30
Pre card string
0 (0x00)
0x1F
P31
Post card string
0 (0x00)
0x20
P32
Pre track string
0 (0x00)
0x21
P33
Post track string
0 (0x00)
0x22
P34
Terminating string
C/R
(0x0D)
0x23
P35
Programmable field separator
“|” (0x7C)
Tk1 SS
0x24
ISO/ABA start sentinel
“%” (0x25)
Tk2-SS
0x25
ISO/ABA 5-bit start sentinel
“;” (0x3B)
Tk3-SS
0x26
ISO/ABA start sentinel
“+” (0x2B)
Tk3-SS
AAMVA
0x27
AAMVA start sentinel
“#” (0x23)
Tk2-SS 7 bit
0x28
7 bit start sentinel (ISO/ABA Track
1 start sentinel)
“@”(0x40)
Tk3-SS 7 bit
0x29
7 bit start sentinel (ISO/ABA Track
1 start sentinel)
“&”(0x26)
ES
0x2B
0x2D
0x2E
0x2F
End Sentinel (for all tracks)
Track 1 Specific End Sentinel
Track 2 Specific End Sentinel
Track 3 Specific End Sentinel
“?” (0x3F)
“?” (0x3F)
“?” (0x3F)
“?” (0x3F)
Track 1, Track 2 and Track 3 Encrypted Data includes the Start and End Sentinel that were
decoded from the card.
