13.3 Electrical rating
ELECTRICAL RATING
Power supply Max peak electrical ratings (comprising
the max power dissipation of the end
user camera/lens and heater)
Maximum power dissipation for end
user fitted camera/lens
230Vac 0.34A, 50/60Hz, 80W 13W
120Vac 0.5A, 50/60Hz, 60W 13W
24Vac 2.2A, 50/60Hz, 53W 13W
12Vdc 2.8A, 34W 13W
Tab. 12
13.4 Cable glands
3/4" NPT CABLE GLAND SELECTION LAYOUT
Zone, Gas Cable gland
type
Certification Operating
temperature
Cable Cable glands
part code
Diameter of
the external
cable (mm)
Under armor
cable diame-
ter (mm)
IIC, Zone 1 or
Zone 2
IIB or IIA,
Zone 1
Barrier IECEX/ATEX/
GOST
-60 / +80°C
(-76°F /
+176°F)
Not armored OCTEXB3/4C 13 - 20.2
Armored OCTEXBA3/4C 16.9 - 26
IIB or IIA,
Zone 2
With gasket IECEX/ATEX/
GOST
-60 / +100°C
(-76°F /
+212°F)
Not armored OCTEX3/4C 13 - 20.2
Armored OCTEXA3/4C 16.9 - 26 11.1 - 19.7
ATEX -20 / +80°C
(-4°F / + 176°F)
Not armored OCTEX3/4 14 - 17
Armored OCTEXA3/4 18 - 23 14 - 17
Tab. 13
