15 Technical data
The installation is type TNV-1, do not
connect it to SELV circuits.
In order to reduce the risk of fire, only use
cable sizes greater than or equal to 26AWG
(0.13mm²).
15.1 General
Built in aluminium and ABS
Epoxypolyester powder painting, RAL9002 colour
Top mount (OTT)
Transmission through toothed belt
Slip-ring
Electronic limit switches
Plug installation thanks to connector and easy
replacement on-site
Zero backlash
Max weight camera+lens 4.5kg (9.9lb)
Encoder for absolute positioning
Configuration of telemetry protocol parameters
through dip-switch for RS485
15.2 Mechanical
Cable glands: 3xM16
Horizontal rotation: continuous
Vertical rotation: from +45° to -20°
Horizontal speed (variable): from 0.02° up to 20°/s
Tilt speed (variable): from 0.02° up to 20°/s
Internal usable area: see drawings
Enclosure glass window (WxH): 112x95mm (4.4x3.7in)
Preset accuracy: 0.02°
Unit weight: 30kg (66lb)
ULISSE MAXI NETCAM, for thermal cameras:
Germanium glass
- Dimensions (Ø): 85mm (3.3in) (external), 70mm
(2.8in) (usable diameter)
- Thick:2mm (0.07in)
- External scratch-resistant treatment: Hard Carbon
Coating (DLC)
- Internal antireflection treatment
- Spectral range: 7.5 ÷ 14μm
- Medium transmittance (7.5μm ÷ 11.5μm): 94%
- Medium transmittance (11.5μm ÷ 14μm): 90%
