ASSEMBLY INSTRUCTIONS FOR

Major lamp parts manufactured in Germany by Holtkötter Leuchten GmbH.
Bulbs manufactured in Germany by Osram GmbH. Final assembly by Holtkötter in South Saint Paul, MN.

Holtkötter

and Holtkötter Leuchten

© Holtkötter

Holtkoetter Bath: Ludwig Series

No. 5583 & No. 5584

5584/4

1. Prepare to install the glass by seating the

plastic wrench inside the glass, aligning
the aluminum ring with the wrench.

2. Holding the wrench in place, set the

glass on the fixture over the bulb and
tighten the aluminum ring on the fixture
hand-tight.

3. The glass should fit snugly against the

fixture. See above.

4. Your wall sconce is now operational.

Bulb Replacement Instructions

1. Be sure to turn the lamp off and allow it to cool before attempting bulb replacement.
2. Remove the glass shade by unscrewing it with the plastic wrench.
3. Remove the old bulb by pulling it straight out of the socket.
4. Follow steps 1-4 under Bulb and Glass Installation Instructions.

Glass Shade Installation Instructions

5583/3
