2
p
rogrAmmABle
F
unctionS
The
Auxiliary, Side 1, Side 2, S, A,
can be programmed with the functions listed below. Please
contact your dealer for further details on these functions.
• Channel Down
• Channel Up
• Clear
• Clock
• Emergency (Trunking)
• GPS Position Display
2
• Key Lock
• Lamp
• None
• Playback
• Scan
• Scan Delete/Add
• Scrambler
• Squelch Off
“Emergency (Trunking)” can be programmed only on the Auxiliary
(orange) key.
2
“GPS Position Display” can be assigned only if one of the COM ports
is configured for GPS.
“Playback” can be programmed only when the optional VGS- board
has been installed.
c
onventionAl
o
perAtion
1 Rotate the selector or press the keys programmed as
Channel Up and Channel Down to select your desired
channel.
2 Press the Squelch Off key (default: Side 1 key) to turn the
Squelch function OFF, in order to monitor any activity on
the channel.
• The icon appears on the display.
• The LED lights green and you will hear background noise.
3 Press the PTT switch and speak into the microphone.
Release the
PTT switch to receive.
• For best sound quality at the receiving station, hold the
microphone approximately ~ 4 cm from your mouth.
