Page 9
261-0400
Cabinet Assembly
ADC-66 R-L
American Dish Service
9
Ref.
No. Part
No.
No.
Req. Description
1
285-6174
1
Filter Weldment, Wash Pump, w/Taper
N/S
281-6211
Rep.
Filter w/O-Ring, Wash Pump
2
289-6611
3
Gasket, O-Ring, Pre-Wash, Wash, and Rinse Taper
3
286-6174
1 Plate, Wash Pump Filter, R-L
4
285-6122
1
Screen Weldment, Wash, Small
5
286-6179
1
Cover, Wash Manifold
6
285-6121 1 Screen Weldment, Wash R-L, Large
7
285-6123
2
Screen Weldment, Rinse Tank
8
286-6176
1
Plate, Rinse Stand Tube, R-L
9
285-6126
1 Cover Weldment, Rinse Float, R-L
10
285-6172
1
Plug Weldment, Rinse Stand Tube
N/S
281-6210
Rep.
Drain Stand Tube w/O-Ring, Rinse Pump
11
285-6197
1
Pre-Wash Screen Basket
12
285-6215
1
Cover Weldment, ADC-66, Pre-Wash Screen Basket
13
285-6162
1
Filter Screen Weldment, Rinse Pump
14
286-6182
1
Guard, Wash Magnet
15
285-6217
1 Bushing Mount Weldment, RH, ADC-66, Idler Arm
16
285-6119
1
Drip Chute Weldment
17
287-6161
1
Baffle, Pre-Wash Tank
18
289-9126
1 Scrap Trap, R-L
19
289-9109
1
Tray, Scrap Trap, Complete
20
289-9114
1
Support, Scrap Trap
21
285-6203
1 Pan Weldment, ADC-66, R-L
22
285-6228
1
Frame Weldment, ADC-66, R-L
23 099-1024 4
Bullet
Feet
24
285-6151
4
Front Panel Mount Weldment, Lower
25
285-6201
2
Panel Weldment, Front
26
285-6216
1 Bushing Mount Weldment, LH, ADC-66, Idler Arm
27
098-1414
4
Bolt, ¼-20 x ½”, TH, SS
N/S
285-6220
1 Cover, ADC-66, R-L, Pre-Wash Transfer Chute
