Page 41
268-1300 R-L
Heater & Water Level Control
ADC-66
American Dish Service
41
Ref.
No. Part
No.
No.
Req. Description
1
285-6177
1
Float Box Weldment, LH
2
291-3014
2
Float Switch w/Holder and Button
2A
291-3013
Rep.
Float Switch Only
2B
291-9109
Rep.
Float Switch Holder
2C
291-9110
Rep.
Button, Float Switch Holder
3
286-6246
2
Float Box Cover
4
285-6179
2
Float Switch Flipper Weldment
5
285-6148
1
Float Rod Tube Weldment, Wash, R-L
6
286-6248
1
Float Rod, Wash
7 285-6176 2
Float
Weldment
8
286-6199
2
Bracket, Float Retainer
9
291-9007
1
Heater, Wash, 18 KW
10
285-6178
1
Float Box Weldment, RH
11
285-6149
1
Float Rod Tube Weldment, Rinse, R-L
12
286-6249
1
Float Rod, Rinse
13
285-6162
1
Filter Weldment, Pumped Rinse Pump
14
291-9003
1
Heater, Rinse, 2.25 KW, 3 Phase
15 291-3012 2
Thermostat
16
286-6175
2
Heater Box Cover
17
098-2201
8
Locknut, 8-32, SS
18
098-2510
16
Washer, 5/16”, SS/Neobond
19
098-1516
8
Bolt, 5/16-18 x 1”, HH, SS
20
098-2501
8
Locknut, 5/16-18, SS
21 289-6613 2
Gasket,
Heater
N/S
286-6231
2
Flange, Heater Sandwich (1 ½” Hole)
N/S
286-6241
4
Washer, Float Switch Rod, ¾” OD x 1/8” ID, SS
