Page 25
263-0100
Wash Pump Assembly
ADC-66 L-R/R-L
American Dish Service
25
Ref.
No. Part
No.
No.
Req. Description
1
291-1002
1
Motor, 3 HP, 3 Phase, w/Shaft
2
282-6301
1
Rear Housing, Wash Pump
3 089-6601 1
Gasket,
Sump
4
289-6606
1
Gasket, O-Ring, Drain Socket Flange
5 098-2510 4
Washer,
SS/Rubber
6
292-2001
1
Seal, Wash Pump
7
289-6603
1
Gasket, Wash Pump, O-Ring
8
282-6303
1
Impeller, Wash Pump
9
284-6151
1
Key, Wash Pump, Impeller
10
098-1613
1
Bolt, 3/8-16 x 1” Lg, HH, SS, w/Lock Strip
11
098-2711
1
Washer, 3/8” ID x 1” OD x .103” Thick, SS
12
282-6302
1
Cover, Wash Pump
13
289-6604
1
Gasket, Wash Pump, Discharge Flange
14
285-6153
1
Discharge Tube Weldment, Wash Pump
15
289-6605
1
Gasket, Wash Pump Intake Flange
16
285-6154
1
Intake Tube, Sump Weldment, Wash Pump
17
285-6157
1
Drain Socket Weldment, Wash
18
289-6607
2
Gasket, Wash Tank Flange
19
292-1013
1
Petcock, ¼” MPT
20
098-1423
6
Bolt, ¼-20 x ½”, HH, SS
21
098-2404
6
Washer, ¼”, SS
22
098-1614
16
Bolt, 3/8-16 x 1” Lg, HH, SS
23
098-2711
8
Washer, 3/8” ID x .103 Thick, SS
24
098-1514
4
Bolt, 5/16-18 x 1 ½”, HH, SS
25
098-2509
8
Washer, 5/16”, SS
26
098-2710
8
Lockwasher, 3/8”, SS
27
098-1502
4
Bolt, 5/16-18 x ½”, HH, SS
N/S
288-1048
Rep.
Pump Assembly, Less Cover, Wash, 3 HP, 3 Phase
