Page 27
263-0300L-R / 263-0400R-L
Rinse Pump Assembly
ADC-66
American Dish Service
27
Ref.
No. Part
No.
No.
Req. Description
1
291-1003
1
Motor, 1/3 HP, 3 Phase
2
282-6307
1
Rear Housing, Pumped Rinse
3
286-6250
1
Plate, Pump Rinse Motor Support, w/Pad
4
284-6163
1
Pump Shaft, Pumped Rinse
5
098-1442
2
Set Screw, ¼-20 x 3/8” Lg
6
292-2002
1
Seal, Pumped Rinse Pump
7
289-6609
1
Gasket, Pumped Rinse Pump
8
282-6308
1
Impeller, Pumped Rinse Pump
9
098-1443
1
Bolt, ¼-28 x 3/8” Lg, HH, SS
10
098-2413
1
Washer, .285 ID x .625 OD x .086 Thick, SS
11
285-6164
1
Discharge Tube Weldment, L-R
12
289-6610
4
Gasket, Flange, Pumped Rinse Pump
13 285-6165 1
Discharge
Flange
Assembly
Weldment
14
282-6306
1
Cover, Pumped Rinse Pump
15
285-6161
1
Intake Flange Weldment Assembly
16
285-6160
1
Intake Tube Weldment
17
285-6163
1
Discharge Tube Weldment, R-L
18
098-1607
8
Bolt, 3/8-16 x 7/8”, HH, SS
19
098-1426
16
Bolt, ¼-20 x ¾”, HH, SS
20
098-2404
32
Washer, ¼”, SS
21
098-2507
16
Locknut, ¼-20, SS
22
092-1002
1
Petcock, 1/8” MPT
N/S
288-1040
Rep.
Kit, Rinse Pump Seal
N/S
288-1049
Rep.
Pump Assembly, Less Cover, Rinse, 1/3 HP, 3 Phase
N/S
288-1050
Rep.
Pump Assembly, Less Flanges, Rinse, 1/3 HP, 3 Phase
