American Dish Service ADC-66 L-R/R-L - Manual (Page 35)

265-1100 L-R Water Inlet
Assembly ADC-66
265-1200 R-L Water Inlet
Assembly ADC-66
American Dish Service
35
Ref.
No. Part No.
No.
Req. Description
1 092-1074 1 Fitting, ¾” Street Elbow, 90°
2 092-9006 1 Y-Line Strainer, ¾”
3 092-9008 Rep. Screen, Line Strainer, ¾” (Repair Part)
4 092-1073 1 Nipple, ¾” Close, Brass
5 092-1107 1 Fitting, Tee, ¾” x ½” x ½”, Brass
6 286-6191 2 Bracket, Plumbing
7 092-5015 2 Valve, Water Solenoid
8 098-9027 4 U-Bolt, ¼-20, SS
9 292-5001 1 Pressure Regulator, ½”
10 092-5045 1 Vacuum Breaker, ½”
11 292-3007 1 Nipple, ½” x 6”, Brass
12 285-6219 1 Air Gap Weldment
13 098-1423 4 Bolt, ¼-20x ½”, HH, SS
14 098-2507 4 Locknut, ¼-20, SS
15 389-6603 1 Gasket, Air Gap
16 299-1004 1 Temperature Gauge, Final Rinse
17 292-1005 1 Reducer Bushing, ½” MPT x ¼” FPT, Brass
18 292-5002 1 Service Cock
19 299-1003 1 Pressure Gauge
20 292-3002 5 Nipple, ½” x 1 ½” Lg, Brass
21 292-3004 2 Nipple, ½” x 2” Lg, Brass
22 292-1014 2 Fitting, ½” Elbow, 90°, Brass
23 292-1007 1 Reducer Bushing, ½” MPT x 1/8” FPT Brass
24 292-1001 3 Fitting, Tee, ½” FPT x ½” FPT x ½” FPT, Brass
25 292-3001 3 Nipple, ½” x 1 ½” Lg, SS
26 292-1003 3 Fitting, Elbow, ½” FPT, SS
27 292-3008 1 Nipple, ½” x 6” Lg, SS
28 292-3003 2 Nipple, ½” x Close, SS
29 292-1004 1 Union, ½”, SS
30 284-6148 1 Mixing Chamber, SS
N/S 284-6147 Opt. Mixing Chamber, Polymer
31 292-1008 2 Pipe Plug, 1/8” MPT, SS
32 292-1002 1 Fitting, Tee, ½” FPT x ½” FPT, ½” FPT, SS
33 292-1012 1 Pipe Plug, ½” MPT, SS
34A 285-6147 1 Inlet Water Duct Weldment, L-R
34B 285-6127 1 Inlet Water Duct Weldment, R-L
35 292-3010 1 Nipple, ½” x 3” Lg, SS
36 392-3001 1 Nipple, ½” x 4 ½” Lg, Brass
37 092-1068 1 Fitting, ½” Comp x ½” MPT, 90° Elbow
38 292-3013 1 Fresh Water Supply Tube, ½” OD x 14 ½” Lg, SS
