261-0300
Cabinet Assembly
ADC-66 L-R
American Dish Service
7
Ref.
No. Part No.
No.
Req. Description
1 098-2507 46 Locknut, ¼-20, SS
2 285-6199 1 Hood Weldment, L-R
3 285-6115 2 Hood End Shield Weldment
4 284-6122 2 Curtain Rod, 5/16” x 20.5”, SS
5 299-1001 2 Curtain, 21” Wide x 17” Tall
6 299-1002 3 Curtain, 23” Wide x 11” Tall
7 284-6121 3 Curtain Rod, 5/16” x 24”, SS
8 285-6233 1 Door Weldment, ADC-66, Wash Tank
9 285-6139 2 Handle Weldment, Front Access Door
10 285-6125 1 Latch Weldment, Door
11 098-8008 4 Cotter Pin, 3/32” x 1”, SS
12 285-6193 1 Pre-Wash Door Weldment
13 285-6205 1 Pre-Wash Door Latch Weldment
14 287-6123 4 Door Guide, SS
15 285-6103 2 Bracket, Door Cut-Off
16 099-4502 2 Switch, Door Cut-Off
17 098-1423 26 Bolt, ¼-20 x ½”, HH, SS
18 098-2404 46 Washer, ¼”, SS
19 285-6116 2 Vent Weldment, Hood End Shield
20 098-1414 16 Bolt, ¼-20 x ½”, TH, SS
21 285-6147 1 Duct Weldment, Inlet Water, L-R
N/S 287-6157 1 Brace, Pan Rear
