Page 21
American Dish Service
21
Ref.
No. Part
No.
No.
Req. Description
1
285-6159
1
Upper Wash Arm Weldment Assembly
2
285-6129
1
Handle Weldment, Upper Wash Arm Mount
3
285-6128
1
Tee Plate Weldment, Upper Wash Arm
4
286-6177
1
Bracket, Upper Wash Arm Mount
5
285-6156
1
Lower Wash Arm Weldment Assembly
6
285-6155
1
Manifold Weldment, Inside Wash
7
285-6166
1
Manifold Weldment, Inside Pumped Rinse
8
285-6168
1
Spray Arm Weldment, Pumped Rinse, Upper, L-R
9
285-6167
1
Spray Arm Weldment, Pumped Rinse, Lower, L-R
10
098-2507
8
Locknut, ¼-20, SS
N/S
285-6158
14
Spray Arm Endcap Weldment
11A
281-6208
1
Spray Arm, Final Rinse, Upper, L-R, SS Jets
11B
281-6206
Spray Arm, Final Rinse, Upper, L-R, Poly Jets
11C
281-6204
Spray Arm, Final Rinse, Upper, R-L, SS Jets
11D
281-6202
Spray Arm, Final Rinse, Upper, R-L, Poly Jets
11E
285-6142
Spray Arm Weld., Final Rinse, Upper, L-R, Arm Only
11F
285-6140
Spray Arm Weld., Final Rinse, Upper, R-L, Arm Only
12A
281-6209
1
Spray Arm, Final Rinse, Lower, L-R, SS Jets
12B
281-6207
Spray Arm, Final Rinse, Lower, L-R, Poly Jets
12C
281-6205
Spray Arm, Final Rinse, Lower, R-L, SS Jets
12D
281-6203
Spray Arm, Final Rinse, Lower, R-L, Poly Jets
12E
285-6143
Spray Arm Weld., Final Rinse, Lower, L-R, Arm Only
12F
285-6141
Spray Arm Weld., Final Rinse, Lower, R-L, Arm Only
13A
284-6146
8
Jets, Final Rinse Spray Arm, SS
13B
284-6145
Jets, Final Rinse Spray Arm, Poly
14
292-1011
2
Cap, ½” FPT, SS
15
292-1003
1
Fitting, ½” FPT 90° Elbow, SS
16
292-3009
1
Nipple, ½” x 21 ½” Lg, SS
17
292-1002
2
Fitting, ½” x ½” x ½” Tee, SS
18
292-3010
1
Nipple, ½” x 3”, SS
19
292-1012
1
Plug, ½” MPT, SS
20
292-3001
1
Nipple, ½” x 1 ½” Lg, SS
21
285-6170
Spray Arm, Pumped Rinse, Upper, R-L
22
285-6169
Spray Arm, Pumped Rinse, Lower, R-L
23
289-6608
2
Gasket, O-Ring, Wash Arm
24
098-1423
2
Bolt, ¼-20 x ½”, HH, SS
25
285-6130
1
Handle Weldment, Wash Arm Mount, Lower
26
285-6198
1
Manifold Weldment, Pre-Wash
27
285-6236
1
Spray Arm Weldment R-L, ADC-66, Lower Pre-Wash
28
285-6237
1
Spray Arm Weldment R-L, ADC-66, Upper Pre-Wash
265-0900 L-R Spray System
Assembly
265-1000 R-L Spray System
Assembly(Shown)
ADC-66
