American Dish Service
29
Ref.
No.
Part No.
No.
Req. Description
1 291-1009 1 Motor, 1 ½ HP, 1 Phase, ADC-66
2 082-6301 1 Rear Housing, Pre-Wash
3 285-6229 1 Suction Tube Extension Weldment, Pre-Wash
4 098-1512 4 Stud, 5/16-18 x 1 5/8”, SS
5 098-2502 4 Nut, 5/16-18, SS
6 092-2001 1 Seal, Pre-Wash Pump
7 089-6309 1 O-Ring, Pump
8 082-6306 1 Impeller
9 285-6241 1 Suction Tube Weldment, Pre-Wash, R-L
10 285-6204 1 Discharge Tube Weldment, Pre-Wash, L-R
11 285-6226 1 Discharge Tube Weldment, Pre-Wash, R-L
12 289-6610 6 Gasket, Flange, Pre-Wash Pump Flange
13 285-6165 1 Discharge Flange Assembly Weldment
14 082-6307 1 Cover, Pre-Wash Pump
15 285-6161 1 Intake Flange Weldment
16 285-6192 1 Suction Tube Weldment, Pre-Wash, L-R
17 285-6230 1 Discharge Tube Extension Weldment, Pre-Wash
18 098-1607 4 Bolt, 3/8-16 x 7/8”, HH, SS
19 098-1426 24 Bolt, ¼-20 x ¾”, HH, SS
20 098-2404 48 Washer, ¼”, SS
21 098-2507 24 Locknut, ¼-20, SS
22 092-1002 1 Petcock, 1/8”
23 098-2503 4 Washer, 5/16”, Copper
263-0600 L-R Pre-Wash Pump
Assembly
263-0700 R-L Pre-Wash Pump
Assembly
ADC-66
