American Dish Service ADC-66 L-R/R-L - Manual (Page 43)

266-0700 L-R
Drain System Assembly
ADC-66
American Dish Service
43
Ref.
No. Part No.
No.
Req. Description
1 292-1029 3 No-Hub Connector, Fitting to Pipe
2 285-6154 1 Intake Tube/Sump Weldment, Wash
3 285-6157 1 Drain Socket Weldment, Wash
4 292-1028 3 No-Hub Connector, Pipe to Pipe
5 289-6606 1 Gasket, O-Ring, Drain Socket Flange
6 289-6605 1 Gasket, Wash Pump Intake Flange
7 089-6601 1 Gasket, Sump
8 285-6211 1 2” Copper Drain Weldment, Rinse, L-R
9 285-6207 1 2” Copper Drain Weldment, Wash, L-R
10 285-6175 2 Rinse, Pre-Wash, Drain Socket Weldment
11 289-6612 2 Gasket, Rinse, Pre-Wash Drain Socket Flange
12 285-6209 1 2” Copper Drain Weldment, Pre-Wash, L-R
13 092-1084 1 Plug, Pipe, 2”
