261-0300
Cabinet Assembly
ADC-66 L-R
American Dish Service
5
Ref.
No. Part No.
No.
Req. Description
1 285-6174 1 Filter Weldment, Wash Pump, w/Taper
N/S 281-6211 Rep. Filter w/O-Ring, Wash Pump
2 289-6611 3 Gasket, O-Ring, Pre-Wash, Wash, and Rinse Taper
3 286-6197 1 Plate, Wash Pump Filter, L-R
4 285-6122 1 Screen Weldment, Wash, Small
5 286-6179 1 Cover, Wash Manifold
6 285-6145 1 Screen Weldment, Wash L-R, Large
7 285-6123 2 Screen Weldment, Rinse Tank
8 286-6200 1 Plate, Rinse Stand Tube, L-R
9 285-6152 1 Cover Weldment, Rinse Float, L-R
10 285-6172 1 Plug Weldment, Rinse Stand Tube
N/S 281-6210 Rep. Drain Stand Tube w/O-Ring, Rinse Pump
11 285-6197 1 Pre-Wash Screen Basket
12 285-6215 1 Cover Weldment, ADC-66, Pre-Wash Screen Basket
13 285-6162 1 Filter Screen Weldment, Rinse Pump
14 286-6182 1 Guard, Wash Magnet
15 285-6216 1 Bushing Mount Weldment, LH, ADC-66, Idler Arm
16 285-6119 1 Drip Chute Weldment
17 287-6161 1 Baffle, Pre-Wash Tank
18 289-9125 1 Scrap Trap, L-R
19 289-9109 1 Tray, Scrap Trap, Complete
20 289-9114 1 Support, Scrap Trap
21 285-6202 1 Pan Weldment, ADC-66, L-R
22 285-6227 1 Frame Weldment, ADC-66, L-R
23 099-1024 4 Bullet Feet
24 285-6151 4 Front Panel Mount Weldment, Lower
25 285-6201 2 Panel Weldment, Front
26 285-6217 1 Bushing Mount Weldment, RH, ADC-66, Idler Arm
27 098-1414 4 Bolt, ¼-20 x ½”, TH, SS
N/S 285-6221 1 Cover, ADC-66, L-R, Pre-Wash Transfer Chute
