American Dish Service ADC-66 L-R/R-L - Manual (Page 17)

268-1100
Conveyor Drive & Tray Track
Control, ADC-66 R-L
American Dish Service
17
Ref.
No. Part No.
No.
Req. Description
1 285-6133 1 Rocker Arm Weldment
2 285-6134 2 Slip Clutch Bar Weldment
3 298-3001 2 Spring, Slip Clutch
4 284-6142 2 Spacer, Rocker Arm
5 298-4001 2 Bushing, 1” OD x ¾” ID x 7/8” Lg
6 284-6141 1 Block, Pillow Bushing, RH
7 284-6139 1 Block, Base, Pillow Bushing
8 284-6149 2 Spacer, Conveyor Connecting Bolt
9 284-6202 1 Bar, Conveyor, ADC-66
10 285-6136 13 Dog Weldment, Conveyor
11 285-6137 2 Exit Dog Weldment, Conveyor
12 285-6135 1 Idler Arm Weldment
13 284-6140 1 Block, Pillow Bushing, LH
14 298-4002 2 Bushing, Idler Arm, 5/8” OD x 3/8” ID x 5/8” Lg
15 284-6143 2 Spacer, Idler Arm, 5/8” OD x 3/8” ID x 3/8” Lg
16 291-1003 1 Motor, 1/3 HP, 3 Ph
17 291-1004 1 Gear Box (53:1)
18 284-6201 1 Key, Conveyor Drive Motor
19 284-6137 1 Key, Cam Block
20 284-6134 1 Cam Block (A), Gear Box Side
21 098-1441 2 Set Screw, ¼-20 x ½” Lg
22 284-6135 1 Cam Block (B), Cam Follower Side
23 286-6189 1 Bolt, Lock, Cam Follower
24 281-6201 1 Bearing, Cam Follower
25 098-1611 6 Bolt, 3/8-16 x 2”, HH, SS
26 098-2710 10 Lockwasher, 3/8”, SS
27 098-1614 6 Bolt, 3/8” x 1”, HH, SS
28 098-1506 2 Bolt, 5/16-18 x ¾”, HH, SS
29 098-1802 2 Bolt, ½-13 x 1 ¼”, HH, SS
30 098-2802 2 Lockwasher, ½”, SS
31 098-1801 1 Bolt, ½-13 x 4”, HH, SS
32 098-2801 1 Locknut, ½-13, SS
33 098-1612 17 Bolt, 3/8-16 x 1 1/8” w/ ¾” Shoulder, HH, SS
34 098-2708 17 Locknut, 3/8-16, SS
35 285-6212 1 Dog Weldment, ADC-66
36 098-2404 18 Washer, ¼”, SS
37 285-6223 1 Tray Track Weldment, ADC-66, R-L, Rear
38 285-6222 1 Tray Track Weldment, ADC-66, R-L, Front
39 098-8009 2 Dowel Pin, 3/16” x 1” Lg, SS
40 285-6213 1 Sequence Bar Weldment, ADC-66, R-L, Pre-Wash
