Page 31
264-0500 L-R
Control System Assembly
264-0600 R-L
Control System Assembly
ADC-66
American Dish Service
31
Ref.
No. Part
No.
No.
Req. Description
1
285-6231
1
Control Box Weldment
2
286-6111
2
Control Box Mounts
3 286-6180 1
Bracket,
Temperature
Gauge
4
299-1005
2
Temperature Gauge, Wash and Rinse Tank
5
299-1004
1
Temperature Gauge, Final Rinse
6 391-5101 1
Terminal
Block
7 285-6240 1
Power
Box
Weldment,
R-L
8
285-6102
1
Cover Weldment, Control Box
9
291-3020
1
Circuit Breaker, 60 Amp, 3 Pole
10 291-3001 4
Contactor
11
291-3002
1
Overload, 3 HP, 3 Phase
12
291-3003
2
Overload, 1/3 HP, 3 Phase
13 291-3009 3
Socket,
Relay
14
291-3005
3
Relay, 110V, DPDT
15
291-9107
1
Din Rail, 22” Lg
16 285-6239 1
Power
Box
Weldment,
L-R
17
287-6104
1
Cover, Power Box
18
291-3006
1
Relay, Mercury, 50 Amp, Wash Heater
19
291-3007
1
Relay, Mercury, 30 Amp, Rinse Heater
20 091-7006 2
Light,
Heater
21
098-2308
2
Wingnut, ¼-20, SS
22
099-4502
2
Switch, Door Cut-Off
23
284-6101
1
Bar, Control Box Safety
24 091-3008 1
Switch,
Master
25
291-3008
1
Relay, Time Delay, 6 Second
26
098-2507
13
Locknut, ¼-20, SS
27
098-1423
2
Bolt, ¼-20 x ½”, HH, SS
28 291-7101 1
Light,
Indicator
29
286-6107
1
Terminal Block Plate
30 391-9101 1
Fuse
Holder
31
291-3023
1
Overload, 1 ½ HP
32
291-3021
1
Circuit Breaker, 20 Amp, 3 Pole
33
091-5010
1
Terminal Block, 110V
34
291-5106
1
Terminal Block, 110V
35
291-5104
2
Terminal Lock, Chemical Dispenser, 2 Pole
36
291-9105
1
Boot, Master Switch Cover
37
096-1002
1
Control Box Lock
38
096-1008
1
Control Box Dummy Lock
N/S 291-3011 3
Switch,
Reed
N/S
291-3022
1
Switch, ADC-66 Pre-Wash, Reed (Normally Open)
