American Dish Service
33
Ref.
No. Part No.
No.
Req. Description
N/S 291-5102 1 Ground Lug
N/S 289-0001 1 Nameplate, ADS
N/S 289-6617 1 Gasket Material, Control Box (78”)
N/S 289-9222 1 Decal, NSF (244 Racks)
N/S 289-9301 1 Wall Chart, Cleaning Instructions, ADS
N/S 291-5110 1 Wire Harness, 3 Phase, ADC-66
N/S 291-9108 4 Shield, Contactor Overload (Anti-Tamper)
N/S 091-4152 1 Bell Box
N/S 091-4004 1 Bell Box Cover
N/S 286-6181 1 Bracket, Conduit (Back of Machine)
N/S 289-9201 1 Decal, Label Set (Blue & Gray)
N/S 289-9202 1 Decal, Label Set (Yellow & Black for Inside Control Box)
N/S 289-9206 1 Decal, Temperature Gauge, Final Rinse, 180°
N/S 289-9226 1 Decal, Wiring Diagram
N/S 291-3016 Opt. Counter, Rack Timer
N/S 286-6219 Opt. Bracket, Rack Timer Counter
N/S 288-1044 Opt. Kit, Table Limit Switch
N/S 288-1051 Opt. Kit, Rack Timer
N/S 291-3015 Opt. Switch Only, Table Limit
N/S 299-1010 Rep. Cover, Temperature Gauge (Screw-On)
N/S 291-5111 Rep. Heater Wiring Harness Kit, ADC-66
264-0500 L-R
Control System Assembly
264-0600 R-L
Control System Assembly
ADC-66
