LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
LCD Bezel M2.5*L5 (NL) 6
LCD Panel M2.5*L5 (NL) 9
LCD Brackets M2*L3 (NL) 8
Camera Bracket M2*L3 (NL) 2
Remove
Inverter Board
Remove
LCD Panel
Remove
LCD Bezel
Remove
LCD FPC Cable
Remove
Camera Module
Remove LCD
Panel from Main
Unit before
proceeding
Remove
LCD Brackets
Remove
LCD Assembly
LCD
Assembly
Back
Panel
Assembly
Remove
Camera Bracket
