8 Chapter 1
Right View
Rear View
No. Icon Item Description
1 ExpressCard/54
slot Accepts one ExpressCard/54 module.
Note: Push to remove/install the card.
2 USB 2.0 ports Connect to USB 2.0 devices (e.g. USB mouse,
USB camera).
3 Optical drive Internal optical drive; accepts CDs or DVDs.
4 Optical disk access
indicator Lights up when the optical drive is active.
5 Optical drive eject
button Ejects the optical disk from the drive.
6 Emergency eject
hole Ejects the optical drive tray when the computer is
turned off.
Note: Insert a paper clip into the emergency eject
hole to eject the optical drive tray when the
computer is off.
7 Modem (RJ-11)
port Connects to a phone line.
8 Kensington lock
slot Connects to a Kensington-compatible computer
security lock.
No. Item Description
1 Ventilation slots Enable the computer to stay cool, even after prolonged use.
