Chapter 3 53
Removing the WLAN Module
1. See “Removing the Turbo RAM module” on page 52.
2. Disconnect the 3 antenna cables from the WLAN board.
3. Move the antenna cables away and remove the two screws on the WLAN board to release the WLAN board.
4. Detach the WLAN board from the WLAN socket.
Step Size Quantity Screw Type
WLAN Module M2*L3.5 (NL) 2
