84 Chapter 3
Removing the Mainboard
1. See “Removing the Upper Cover” on page 71.
2. See “Removing the Modem Module” on page 82.
3. Disconnect ExpressCard and Bluetooth cables attached to the mainboard.
4. Remove the two securing screws on the mainboard.
Step Size Quantity Screw Type
Mainboard M2.5*L6.5 (NL) 2
