Radio, HD Radio™ tuner Operation
Radio/ HD Radio tuner Basic Operation
Most functions can be controlled from the source control screen.
NOTE
• Set the remote controller mode switch to AUD mode before starting operation, see
• HD Radio broadcasting can be received only by the DNN991HD.
• HD Radio broadcasting is for North American sales area only.
• The screen shot below is for tuner. It may be different from the one for HD Radio broadcasting.
Simple Control screen
List Control screen
2
6
2
7
1
7
3
3
4
4
5
8
1 PS/Station name display
Displays the PS name or station name.
2 Information display/Control switching area
Displays the following information.
• Picture: The picture data or station Logo data is displayed if available from current content.
• [FM1] etc.: Band display
• MHz/kHz: Frequency display
• Preset #: Preset number
• HD# (HD Radio tuner only): Channel display
Touch to switch between the Simple Control and List Control screen.
3 Multi function key
Touch to switch the multi function menu. For details on the menu, see
4 Preset key/Multi function menu
Recalls the memorized station or channel. When touched for 2 seconds, stores the current receiving
station or channel in memory.
When switched, various functions can be performed by using keys in this area.
For details on the menu, see
5 Sub function key
Touch to display “Sub function menu” (7 in this table).
Continued
