12 | KDC-U7056DAB/ KDC-U7056BT/ KDC-U7056BTL English | 13
4. DSP settings
4-1. Audio control
You can adjust the audio control items.
1 Press [SRC] to select a source other than
Standby (“STANDBY”).
Refer to
(page 10) .
2 Press [Control] knob.
Enters the Function setting mode.
3 Select “Audio Control” using [Control] knob.
For how to use [Control] knob, refer to
<3-3. How
to select the item> (page 9) .
4 Select a audio control item using [Control]
knob.
Display Overview
“SubWoofer Level” You can set subwoofer level.
“–15” — “0” — “+15”
“Preset Equalizer” [1][4] Select from among preset equalizer curves
to set the sound quality.
“ User ” [2] / “Natural”/ “Rock”/ “Pops”/
“Easy”/ “Top 40”/ “Jazz”/ “Powerful”/
“iPod”(During iPod source only)
“Manual Equalizer”” [1][4] Set the equalizer curve manually.
Refer to <4-2. Manual equalizer control>
(page 13) .
“Pro Setup”
“DSP Set” [7] Turn on/off the DSP function.
“Bypass”: Disables the DSP function.
“ Through ”: Enables the DSP function.
“Car Type” [4] To get clear sound, set the sound
environment according to the location and
size of physically installed speakers with
reference to the followings:
<4-3. Car type selection> (page 13)
<4-4. Speaker setting> (page 14)
<4-5. X’Over setting> (page 15)
<4-6. Listening position setting> (page
16)
<4-7. Delay time control> (page 16)
<4-8. Channel level fine adjustments>
(page 17)
“Speaker Setting” [4]
“X’Over” [4]
“DTA Settings” [4]
“Sound Enhancements” [4]
“Supreme” [5] Turns ON/OFF the Supreme function.
Can be set while Audio file source of USB/
CD and iPod source.
“ ON ”/ “OFF”
“HIGHWAY-SOUND”
[3]
Compensates the low volume or bass
sound being lost by road noises to make
vocal sound clearer.
“ OFF ”/ “Low”/ “Middle”/ “High”
“Space Enhancer” [3] Virtually enhances the sound space using
the DSP.
“ OFF ”/ “Small”/ “Medium”/ “Large”
“Sound Realizer” Virtually makes the sound more realistic
using the DSP.
“ OFF ”/ “Level1”/ “Level2”/ “Level3”
“Sound Elevation” Virtually raises the sound field using
the DSP.
“ OFF ”/ “Low”/ “Middle”/ “High”
“Volume offset” Sets each source’s volume as a difference
from the basic volume.
“–8” — “ 0 ” (AUX: “–8”— “+8”)
“Rear Mute” [6] Sets the Rear channel Mute.
“ON”/ “ OFF ”
“SubWoofer Mute” Sets the Subwoofer Mute.
“ON”/ “ OFF ”
“Audio Preset” You can register the values set the Audio
control items.
Refer to <4-10. DSP preset> (page
18) , <4-11. DSP preset recall> (page
19) .
“Bass Boost” [4] Sets the Bass Boost level in 3 steps.
“ OFF ”/ “Level1”/ “Level2”/ “Level3”
“Loudness” [4] Makes the sounds at high and low
frequencies louder.
“ OFF ”/ “Low”/ “High”
“Balance” Adjusts left/right speaker balance.
“Left15” — “ 0 ” — “Right15”
“Fader” [6] Adjusts front/rear speaker balance.
“Rear15” — “ 0 ” — “Front15”
( Colored text : Factory setting)
[1] You can select for each source.
[2] “User”: The Equalizer curve set in the section <4-2.
Manual equalizer control> (page 13) is recalled.
[3] This function is not effective for the Tuner and Digital
radio source.
[4] Displayed only when “DSP Set” is set to ”Through”.
[5] Audio file source only
[6] Not displayed while using 3 way system.
[7] Unable to change the setting while using 3 way system.
5 Select a value using [Control] knob.
Exiting from the Function setting mode
Press and hold [ 1/6].
When you selected “iPod” for “Preset Equalizer”
• When you selected “iPod” for “Preset Equalizer”, next select
an equalizer curve. Select a desired equalizer curve using
[Control] knob from among 22 equalizer curves displayed
after you selected “iPod”.
4-2. Manual equalizer control
You can adjust the equalizer curve manually.
1 Press [SRC] to select a source other than
Standby (“STANDBY”).
Refer to
(page 10) .
2 Press [Control] knob.
Enters the Function setting mode.
3 Select “Audio Control” > “Manual Equalizer”
using [Control] knob.
For how to use [Control] knob, refer to
<3-3. How
to select the item> (page 9) .
4 Select a equalizer control item using [Control]
knob.
Display Description Range
“Gain” Adjust the gain of each band. -9 – 0 – +9 dB
“Q Factor” Adjust Q of each band. 1.35/ 1.50 / 2.00
“Bass EXT” Adjust the gain of lower
frequencies than 62.5 Hz to the
level equivalent to 62.5 Hz.
“ OFF ”/ “ON”
( Colored text : Factory setting)
When “Bass EXT” and “Q Factor” are selected, skip
step 5.
5 Select a Band using [Control] knob.
“BAND1”; 62.5 Hz, “BAND2”; 100 Hz,
“BAND3”; 160 Hz, “BAND4”; 250 Hz,
“BAND5”; 400 Hz, “BAND6”; 630 Hz,
“BAND7”; 1 kHz, “BAND8”; 1.6 kHz,
“BAND9”; 2.5 kHz, “BAND10”; 4 kHz,
“BAND11”; 6.3 kHz, “BAND12”; 10 kHz,
“BAND13”; 16kHz
6 Select a value using [Control] knob.
Exiting from the Function setting mode
Press and hold [ 1/6].
When the “Manual Equalizer” item is not displayed
• This function is not available when “iPod” is selected for
“Preset Equalizer”.
4-3. Car type selection
You can compensate the delay of the sound arrival
time by selecting your environment from the car
types.
1 Press [SRC] to select a source other than
Standby (“STANDBY”).
Refer to
(page 10) .
2 Press [Control] knob.
Enters the Function setting mode.
3 Select “Audio Control” > “Pro Setup” > “Car
Type” using [Control] knob.
For how to use [Control] knob, refer to
<3-3. How
to select the item> (page 9) .
4 Select a car type using [Control] knob.
Display Car type
“OFF” Not compensating.
“Compact” Compact car
“Full Size Car” Full size car
“Wagon” Station wagon
“Minivan” Minivan
“SUV” Sport-utility vehicle
“Minivan (Long)” Long Minivan
Exiting from the Function setting mode
Press and hold [ 1/6].
To set the delay time finely
• You can compensate the distances in more details by using
<4-7. Delay time control> (page 16) function.
