6. SysEx Messages

Channel Number/ Output Type

Bitwise:

x c3 c2 c1 c0 m2 m1 m0

Note or CC (m2:m0) :

Min: 0 (Note)

Max: 1 (CC)

Values 2-7 can be sent but are invalid states.

MIDI Channel (c3:c0):

Min: 0 (MIDI Channel 1)

Max: 15 (MIDI Channel 16)

Encoders Absolute/ Relative

This Data Byte determines whether each encoder outputs in Absolute Mode or Relative (2’s

Compliment Mode).

Bitwise:

x e7 e6 e5 e4 e3 e2 e1 e0

Bits per Encoder:

0 = Absolute Mode

1 = Relative Mode

Default:

1 (0x01)

Large navigation encoder [e0] outputs in Relative

Mode, all other encoders output in Absolute

Mode.

Encoder Speeds A and B

These Data Bytes determine how much encoders increment per click.

Min:

1 (Value Increments by 1 for each click)

Max:

15 (Value Increments by 15 for each click)
