Page 37
6. SysEx Messages
37
09 : Map LED Rings
This message changes the MIDI mapping of all LED rings (Channel, CC Only, and Number).
Total Bytes:
19
Data Bytes:
12
Data Bytes per LED Ring:
2
1st Data Byte Received:
Mapping Number
2nd Data Byte Received:
Channel Number/ Output Type
Message for Default Settings:
< 240, 00, 01, 106, 01, 09, 0, 79, 0, 80, 0, 81, 0, 82, 0, 83, 0, 84, 247 >
13 : Set Settings Channel
This Message changes the Settings Channel.
Total Bytes:
8
Data Bytes:
1
1st Data Byte Received:
MIDI Channel
0 = MIDI Channel 1
15 = MIDI Channel 16
Message for Default Settings Channel (MIDI Channel 16):
< 240, 0, 1, 106, 01, 13, 15, 247 >
