5. The Settings Channel
25
4RM = Ring Mode
4SB = Security Bit (0 = ignore message, 1=accept message)
4ES = Encoder Speed
4EOM0 = Encoder Output Mode (0=absolute,1=relative
4EOM1
4ENCR = Encoder Relative Local Control
4ENCA = Encoder Absolute Local Control
4ANA = Analog Local Control
5.1 Encoder Settings
5.1.1 Default Settings
Settings Channel: 16
Encoder Mappings: Min: CC56
Max: CC62
5.1.2 Encoder Response Table
Value
Received by
Tweaker Expected Change to Encoder Properties
Ring Mode
Encoder
Output Mode Encoder Speed
(global)
0-63
64 Fill Relative
65 Walk Relative
66 EQ Relative
67 Spread Relative
68 Fill Absolute
69 Walk Absolute
70 EQ Absolute
71 Spread Absolute
72 Fill Relative 1
