6. SysEx Messages
36
07 : LED Ring Output Modes
This Message changes the display mode of all LED rings (Walk, Fill, Spread, or EQ).
Total Bytes:
9
Data Bytes:
2
LED Rings per Data Byte:
3
Bits per LED Ring:
2
1st Data Byte Received:
LED Rings 1-3
(Bitwise: x 0 r3h r3l | r2h r2l r1h r1l )
2nd Data Byte Received:
LED Rings 4-6
(Bitwise: x 0 r4h r4l | r5h r5l r6h r6l )
Valid Output Modes:
0: Fill
1: Walk
2: EQ
3: Spread
Message for Default Settings (All EQ Mode):
< 240, 0, 1, 106, 01, 07, 42, 42, 247 >
08 : Map RGB LED’s
This Message changes the MIDI mapping of all RGB LED’s (Channel, CC Only, and Number).
Total Bytes:
83
Data Bytes:
76
Data Bytes per RGB LED:
2
1st Data Byte Received:
Mapping Number
2nd Data Byte Received:
Channel Number/ Output Type
Message for Default Settings:
< 240, 00, 01, 106, 01, 08, 0, 1, 0, 2, 0, 3, 0, 4, 0, 5, 0, 6, 0, 7, 0, 8, 0, 9, 0, 10, 0, 11, 0, 12, 0, 13, 0, 14, 0, 15,
0, 16, 0, 17, 0, 18, 0, 19, 0, 20, 0, 21, 0, 22, 0, 23, 0, 24, 0, 25, 0, 26, 0, 27, 0, 28, 0, 29, 0, 30, 0, 31, 0, 32, 0,
33, 0, 34, 0, 35, 0, 36, 0, 37, 0, 38, 247 >
