57' rolling chopper mounted harrow layout – Summers Hydraulic Fold Coil User Manual
Page 94
HYDFLD ROLLING CHOPPER 57'
7/26/2012 9RC0570.iam/
36"
86 3/4"
157 3/4"
199"
276 3/4"
299 1/4"
36"
87"
157 3/4"
199 1/4"
276 3/4"
299 1/2"
8H2310
8HD5583
8HD5099
8HD5593
8HD5593
8HD5593
8HD5593
8HD5583
8HD5099
8J4290
8HD5270
8HD5260
8K5515
3/4 X 4 X 6"
8H1499
8H1499
8X0101
4 3/4"
SECTION 2 - ASSEMBLY
SECTION 2 - ASSEMBLY
2-84
