5' rolling chopper mounted harrow layout – Summers Hydraulic Fold Coil User Manual
Page 92
HYDFLD ROLLING CHOPPER 53.5'
7/26/2012 9RC0535.iam/
8H2314
8HD5563
8HD5563
8HD5563
8HD5593
8HD5583
8HD5563
8HD5563
8HD5563
8J4290
8HD5270
8HD5260
8HD5150
8H1499
8H2310
8H1499
8X0101
8K5515
3/4 X 4 X 6"
8H2310
24"
77"
161"
219"
268 1/2"
289"
42"
77 1/4"
161"
219"
268 1/2"
289 1/4"
SECTION 2 - ASSEMBLY
SECTION 2 - ASSEMBLY
2-82
