21'-30' narrow center hydraulic assembly, 26'-44' hydraulic assembly, Hydraulic system 21’-30’ narrow center -9 – Summers Hydraulic Fold Coil User Manual
Page 107: Hydraulic system 26’-44’ standard center -9
HYD22_30
9/24/2013
8Z1111/
ROD
BASE
BASE
BASE
BASE
ROD
ROD
ROD
8C0432 (2X)
4 X 32"
8D9418A - SEAL KIT
8D9316 (2X)
3.5 X 16"
8D9350 - SEAL KIT
8J6010
8J7216
8J5620
8J5300
8J6010
8J5300
8D3212
8J5510
HYDRAULIC LIFT IMPLEMENT
HYDRAULIC ASSEMBLY
21' - 30' NARROW CENTER UNITS
8N3288
3/8"x288"
8N3084 (4X)
3/8"x84"
8N3048
3/8"x48"
8N3060
3/8"x60"
SECTION 4 - PARTS
4-9
