Summers Hydraulic Fold Coil - Manual (Page 101)

DETAIL A
DETAIL B
DETAIL C
DETAIL D
A
B
C
D
18' THROUGH 50' FRAME 9/4/2012 9PD5075.iam/
HYDRAULIC FOLD IMPLEMENT
18'-50' STANDARD CENTER
8D0724
OPT.
8X0262
3/4" LN
3/4X6"
GR 8
8C5060 - DROP EXT.
8C2330 - SINGLE AXLE LESS
614 HUB (18-21' 0NLY)
8C2340 - SINGLE AXLE
W/614 HUB (18-21' ONLY)
8X0099
5/8" X 6-3/4"
8K1610
8C6120
8X0075
1/2 X 6"
8D9110
8X0303
1/2" LW
8X0240
1/2" N
8X0250
5/8" N
8X0304
5/8" LW
3 SECTION
ONLY
8D8500
8X0110
3/4 X 1.25"
8X0318
3/4" FW
8X0000
8X0223
1/4" FN
8D8490
8X0318
3/4" FW
8X0309
1" LW
8X0280
1" N
8D0720
8X0140
1 X 7"
8C5050
8D8523
8C5090
8C5080
8C2310
8X0072
1/2" X 3-3/4"
8X0143
1X5"
8C2320
8X0281
NY-LOCK 1"
8X0107
3/4 X 2"
8X0242
NY-LOCK 1/2" N
8C0250
8R6914
8K7033
8C5600
8X0306
3/4" LW
8X0260
3/4" N
8X0242
NY-LOCK 1/2" N
8X0330
1/2" FW
8C1470
8C5150
8K5515
3/4 X 4 X 6"
8C5140
8X0306
3/4" LW
8X0260
3/4" N
8X0285
1 1/2" N
8X0315
1-1/2" LW
8K1682C
8X0240
1/2" N
8X0303
1/2" LW
8K5515
3/4 X 4 X 6"
8X0306
3/4" LW
8X0260
3/4" N
8K1682C
8X0285
1 1/2" N
8K5515
3/4 X 4 X 6"
8X0306
3/4" LW
8X0260
3/4" N
8D3152
8C5120
8A1004
5" HC
8Z1000
8X0203
3/8" FN
8T4385
8A1156
3/8 X 4-1/16 X 5"
8C5070 - 5'
8C5100 - 9'
SECTION 4 - PARTS SECTION 4 - PARTS
4-3
