AMETEK 1746 LDT Interface Card - Manual (Page 3)

i Installation & Programming Manual
1080 North Crooks Road
Clawson, MI 48017-1097
Phone: (248) 435-0700
FAX: (248) 435-8120
Internet: www.ametekapt.com
www.ametek.com
Copyright 2006 by AMETEK
All Rights Reserved
AMETEK has checked the accuracy of this manual at the time it was printed. Any comments you may have
for the improvement of this manual are welcomed.
AMETEK reserves the right to revise and redistribute the entire contents or selected pages of this manual.
All rights to the contents of this manual are reserved by AMETEK.
This product incorporates technology which is licensed by Rockwell Automation, Inc. Rockwell Automation
has not technically approved, nor does it warrant or support this product. All warranty and support for this
product and its application is provided solely by AMETEK.
Preface
This manual will instruct the user in installing and programming the Series 1746L Gemco PLC LDT
Interface Module. Chapter 2 contains information on installing the 1746L PLC LDT Interface Module and
the LDT/Cable. Chapter 3 provides instructions on programming the 1746L, while Chapter 4 contains an
Application Example. Specifications and a Wiring Diagram can be found in Appendix A and Appendix B,
respectively.
