Appendix A: Specifications
Installation & Programming Manual
18
Appendix A: Specifications
Power Requirements:
0.500A max. @ 5 Vdc
0.0A @ 24 Vdc
+24Vdc Output: Protection: Thermal,
Over-Current, Short Current: 300 mA @ +24Vdc Max.
Regulation: +24Vdc +/- 5% Max
Resolution:
0.001” or 0.01mm
Update Times (per LDT):
No Recircs
w/Recircs
w/Velocity
(w/o Data Format) 4.0mS
6.0mS
(w/ Data Format) 4.5mS
6.5mS
w/o Velocity
(w/o Data Format) 3.0mS
4.5mS
(w/ Data Format) 3.5mS
5.0mS
Velocity:
0.1” accuracy
0.001” resolution
Temperature Range:
Operating:
32 - 131°F (0 - 55°C)
Storage:
0 - 150°F (-17 - 65°C)
Auxiliary Inputs:
10 - 30Vdc max. @ 3 mA (active when power is applied)
Module ID Code:
3535
(Reserve 8 input and 8 output words I/O image table)
I/O Isolation:
500 Vac
